Details
Capacity
2,048Wh
Fuel Type
Battery Powered
Dimensions
448mm (L) x 225mm (W) x 324mm (H)
Dry Weight
Approx 22kg
Number of Ports
AC Output × 4
USB-C × 4
USB-A × 4
SDC × 2
AC Input × 1
AC Output (Bypass Mode)
DYM2000L: AC 100- 120 V, 12 A
DYM2000H: AC 220-240 V, 10 A
USB-A Output
5 V, 3 A
9 V, 2 A
12 V, 2 A
Max output power per channel: 24 W
Supports QC 2.0 and QC 3.0 protocols with a maximum output power of 24 W when only 1 port is used; when 2 or more ports are used simultaneously, each port defaults to 5 V/2 A/10 W output, and negotiated high voltage is not supported.
USB-C Output
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
28 V, 5 A (EPR)
C1 and C2 port max output power: 140 W*
C3 and C4 port max output power: 65 W
From left to right, the max output power for C1 and C2 ports is 140 W, and for C3 and C4 ports is 65 W.
* Each USB-C port supports a max output power of 140 W. The device being charged must support the PD 3.1 protocol and use a USB cable that meets EPR specifications.
SDC Output
SDC 1 and SDC 2: 9-28 V, max current: 12 A
SDC Input
SDC 1 and SDC 2: DC 32-58.4 V, max current: 60 A
