Details
Capacity
1,008Wh
Fuel Type
Battery Powered
Dimensions
314mm (L) x 212mm (W) x 216mm (H)
Dry Weight
Approx 11.5kg
Number of Ports
AC output port × 2
USB-C × 1
USB-C Retractable Cable × 1
USB-A × 2
SDC × 1
AC Input × 1
AC Output
Low voltage:
AC 100-120 V, 50/60 Hz, max current: 10 A, max 1000 W (continuous at 800 W)
AC 100-120 V, max current: 14.4 A, max 1440 W (Bypass mode)
High voltage:
AC 220-240 V, 50/60 Hz, max current: 4.5 A, max 1000 W (continuous at 800 W)
AC 220-240 V, max current: 10 A, max 2200 W (Bypass mode)
USB-A Output
5 V, 2.4 A
Max output power per channel: 12 W
USB-C Output
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
Max output power per channel: 100 W*
* The USB-C port supports a max output power of 100 W. When charging devices concurrently via the retractable cable and USB-C port, the total output power is 150 W, with the retractable cable providing up to 100 W and the USB-C port up to 50 W.
SDC Output
SDC: 9-28 V, max 300 W
AC Input
Low voltage:
AC 100-120 V, 50/60 Hz, max current: 10 A, max 1000 W (continuous at 800 W)
AC 100-120 V, max current: 14.4 A, max 1440 W (Bypass mode)
High voltage:
AC 220-240 V, 50/60 Hz, max current: 4.5 A, max 1000 W (continuous at 800 W)
AC 220-240 V, max current: 10 A, max 2200 W (Bypass mode)
USB-C Input
Max charging power: 100 W
SDC Input
SDC: 9-28 V, max 400 W
