Details
Capacity
7,680Wh
Fuel Type
Battery Powered
Dimensions
550mm (L) x 487.5mm (W) x 669mm (H)
Dry Weight
85.5kg
AC Output
Rated Power: 6.2kW (up to 37.2kW/6 in parallel)
Rated Voltage/Frequency: 230V AC ±10% 50Hz/60Hz (configurable)
Rated Current: ~27A @ 230V (per unit)
Single-Phase: Native
Apparent Power: 6.2kVA per unit
Overload Capacity: 120% for short duration (automatic protection & recovery)
Outlet: 16-amp x 3 | 32-amp x 1
AC Input
Rated Power: up to 6kW AC charging per unit
Rated Voltage/Frequency: 230V AC, single-phase
Single Phase/Current: Max ~32A input
THDI: <3% (grid-compliant inverter design)
AC-Connection: Dedicated AC input connector with breaker protection
Other Information
Ingress Rating: IP54 (industrial outdoor-ready)
Scalability: Up to 6 units in parallel (support single-phase and three-phase system)
Fire Suppression System: Battery-level BMS protection, Multi-layer electrical & thermal protection
Noise Level: <50 dB
Standard Compliance: IEC UN38.3 MSDS
